Features
- 120-347Vac Input
- BLE/DALI2.0/LORA/0-10V/UART Protocol Convert
- 6kV Surge Protected (only with Upowertek LED Drivers)
- +/-1% Accuracy Power Report
- DALI Output Version Able to Power DALI Sensor
- Internal Relay
- Inrush Current Control
- IP66 Waterproof
- NFC Programming
- LED Module and LED Driver Temperature Reporting by NTC
- 0-10Vor DALI or UART Output
- Historical Data Records
Application
Only Work with Upowertek Drivers
(Please contact with sales@www.upowertek.cn for more details about this type)
| Model Number | Input Voltage | Control Input Protocol | Dimming Output | Programming Function | External LED Module Temperature Signal Input |
| PMR-D2A-NRZ | 120-347Vac | DALI2 | 0-10V | NFC | – |
| PMR-D2A-KRZ | 120-347Vac | DALI2 | NFC | Yes | |
| PMR-B2A-NRZ | 120-347Vac | Bluetooth | NFC | – | |
| PMR-B2A-KRZ | 120-347Vac | Bluetooth | NFC | Yes | |
| PMR-L2A-NRZ | 120-347Vac | LORA | NFC | – | |
| PMR-L2A-KRZ | 120-347Vac | LORA | NFC | Yes | |
| PMR-B2D-NRZ | 120-347Vac | Bluetooth | DALI | NFC | – |
| PMR-D2U-KRZ | 120-347Vac | Bluetooth | NFC | Yes | |
| PMR-B2D-NRZ | 120-347Vac | LORA | NFC | – | |
| PMR-D2U-KRZ | 120-347Vac | LORA | NFC | Yes |
Z = U, UL cable with ground wire S, VDE cable/Class I D, VDE cable/Class II
Contact Sales for UART version with LED driver temperature feedback function.
